Piano Regulating Tools

Weighing only a few ounces, the Tautline Tool is an ideal jig for simulating string height in the field (works great on your workbench as well). Assembly is quick. Just use the piano's action mount screws to hold the...

Plastic gauge for quickly measuring:   1.  Let-off 1/8”   2.  Hammer Blow Distance 1-7⁄8”   3.  Backcheck Distance 5/8”

This tool is used to regulate lost motion on W. & B. drop actions. It has a 1/4 inch recessed blade, is 5 inches long, and chrome plated. Used with our combination tool handle.

Considerable time was spent by Schaff to research and test a new method of casting for these pre-World War I designed wire bending pliers.  Made of stainless steel these pliers, originally made for piano factory use, have great leverage because of...

Set of 52 brass spring clip leads weighing 3 oz. each, comes with a reinforced fiberboard case with straps that measures 6-1/2" square.  These leads, which fit over the backchecks, replace the weight of the grand action when the keyboard is removed...

This tool is designed with a 1/8" long recessed opening that helps locate and regulate grand repetition lever screws along with spade head regulating screws that are 1/8" wide.  1/8" diameter shanks and chrome plated.  9" long.  This tool...

This tool is designed to correctly space grand hammer flanges which will bring the shanks and hammer heads into alignment.  Tool is 6-1/2 inches long.  One end has a 3/8" opening and the other end has a 5/16" opening.

The Jaras 4-in-1 Grand Regulating Rack is a tool that has been developed to take the guesswork out of grand piano regulation.  This tool performs the regulating functions with precision.  It is a quality made item which will last a lifetime and...

Offset Ratcheting Screwdriver Set with 4 blades - 1/4" and 3/8" slotted and #1 & #2 Phillips head blades.  Nickel-plated handle and black oxide finish on blades.  This is a handy tool to have to access hard to reach places.  This is...

This handy tool has a recessed blade to fit over the piano damper head screws.  The blade is 3/16" long and the length of the tool is 8".  This tool is designed to be used with any of our combination tool handles.

Tool for leveling sharps.  Includes float pin with a set screw.

Set of 5 gauges used to measure the aftertouch on either a grand or vertical piano.  The thicknesses included are .027", .037", .044", .055" and .062".  There is a slot in the end to fit around the key pin.  The gauge can be put either...

Straight burnishing tool for easing the grand piano damper guide rail bushings.  This tool is designed to be used in a power drill and is used to iron the felt by causing friction to build up heat on the felt as the tool burnishes the felt. ...

8" chrome plated screwdriver with 1/4" wide blade and a 3/16" wide shaft.  For use with any of our combination tool handles.

Pointed capstan regulating tool with a straight end and a bent end to accommodate more angles on the tool.  Tool is 8" in length.  This tool is used to adjust the wood dowel capstans or any capstan with holes for the regulating tool for...

Pointed Capstan regulating tool designed to regulate wood dowel capstans or any capstans with holes for the regulating tool.  8 inch long shaft with a wood handle for a total tool length of 11-1/2 inches.

Helpful tool for adjusting the let-off on grand pianos.  Ratcheting action which can be used to adjust the screw with a ratcheting action.  One side is used for turning the screws in and the other side is for turning the screws out.

Solid Wood Handle (4" long) 3" steel shaft and collet Steel collar which tightens by turning clockwise for a firm grip on the tool shaft For use with a large variety of piano repair and regulating tools Made in the USA This...

36" long magnetic strip designed to use in setting letoff on grand or vertical pianos.  Strips available in either 1/8" or 1/16" thickneses.  Please choose thickness below.  Strip will stick to plain wire strings.  You can then set...

Grand & Upright Backcheck Bender Dual purpose backcheck bender, one end bends wires forward or backwards on grand pianos, while the other end is for upright backchecks.
