Quality new replacement grand piano hammer shanks with attached flanges. Made by Tokiwa of Japan. Available individually or in a set of 90. Several styles available:
| Shank & Flange Type | Center Pin to Knuckle Core | Flange Screw to Center Pin |
| New York Steinway Type | 16 mm | 23 mm |
| Hamburg Steinway Type | 17 mm | 24 mm |
| Yamaha "New" Type | 17 mm | 24.5 mm |
| Yamaha "Old" Type | 17 mm | 22 mm |
| Kawai KG1 Type with wood shank and composite flange | 17 mm | 24 mm |
| Baldwin "Old" Bore Type | 17 mm | 23 mm |
| Baldwin "New" Bore Type | 17 mm | 25 mm |
| Wessel, Nickel & Gross Type | 17 mm | 25 mm |
| Aeolian Narrow Type | 17 mm | 22 mm |
| Aeolian Long Style | 17 mm | 27 mm |
| Renner Type | 17 mm | 23 mm |
| Knabe Type | 17 mm | 24 mm |
| Renner Type w/ Adjustable Flange | 17 mm | Adjustable |
The flanges are all 12 mm wide except for the Aeolian Narrow Type which is 11 mm wide. If you are putting the old hammer onto a new shank you'll need a tool for removing the old hammer. Here is a link to the tool in our store: Grand Hammer Shank Press
**Special note about Yamaha New Shanks: There are two different types for the Yamaha New shanks, one is the octagonal shanks which are for the notes with dampers, generally this would be notes 1-71. The others are an oval shape which are for notes 72-88 or the notes without dampers. The reason for this is to compensate for the weight difference. Please contact us if you need a full set of Yamaha New shanks.
